- Configurable OpenSCAD calendarmakerworld.com Configurable calendar by Rikudou
A fully customizable calendar created in OpenSCAD!FeaturesThe days are always correct - uses an algorithm to calculate the correct day for any date. So if you want to print a calendar for 2077, rest assured that the model will calculate the correct day for the 1st of January (it's Friday, btw).G...
So, a few days ago I've written about a then work-in-progress configurable calendar model and now we're ready to roll!
Features
- The days are always correct - uses an algorithm to calculate the correct day for any date. So if you want to print a calendar for 2077, rest assured that the model will calculate the correct day for the 1st of January (it's Friday, btw).
- Generate only select months - the full model measures 240x240 mm, which might be quite large for some smaller printers. You can generate only months 1-6 and then separately months 7-12 and voilá, it fits.
- Choose how many months are on each row - what would it help cutting the calendar in half by only selecting half of the months if you couldn't fit 3 columns on your print bed? Well, just change the amount of columns, of course! Set it to 2 and the model fits again.
- Custom holidays - every country has different holidays and here you can put them all easily!
- No AMS or MMU? No problem! - supports printing both with AMS/MMU and without. With a simple toggle you can switch between multi material mode and a mode where each colored part has different height for manual color switching
- Are Saturdays worth celebrating? - you decide! A simple toggle to toggle whether Saturdays have that holiday/Sunday color or not
- Magnet or hook holes? - or both? You can configure the diameter, width, height and whatnot of either or both.
- What the f…ont! - choose your font, choose your font size.
- No hablo English? - just translate the calendar to your language! Title, month names and day names are all translatable.
- Study: Sanitation Effectiveness of 3D-printed Parts for Food and Medical Applications
> Abstract Sanitation effectiveness of 3D-printed parts for food and medical applications has been established in a 4-month lab study and controlled tests. The present study examined the continued use of sanitation techniques across 3 more months of testing and experimentation in household kitchens. Multiple specimens of the most common thermoplastics for Fused Filament Fabrication (FFF), were printed with a range of settings to test for pathogen contamination, biofilm production, bacteria, or other pathogens masking (hiding) in the layer lines, gaps, and other imperfections of said prints. This study investigates methods of sanitation and cleaning to reduce or eliminate pathogens along with its biofilms from the defects and interstitial spaces that naturally occur in FFF printing. Results from various testing methods used in hospitals and FDA approved microbial surface testing, indicate that 3D printed parts of PLA/PLA+ (Polylactic Acid), and PETG (Polyethylene terephthalate glycol) can be cleaned to safe levels using warm water (120 °F), and non-concentrated dish soap. Examination and verification of cleanliness were completed via Petri dish preparations, and protein residue testing. It was found that Colony Forming Units (CFU) and Plaque Forming Units (PFU) had been reduced by 90%. Experimental results indicate that using 2g of baking soda, when used with soapy water, eliminates biofilms by chemical and physical action, neutralizes acidic bacteria, and removes mucus. It is recommended and tested by surgical technicians, that a 2-minute room temperature bleach water soak (200ppm), after washing and rinsing should be done to ensure pathogens are at safe levels. Acetic acid from vinegar was tested as well via petri dish for CFU reduction and can effectively eradicate biofilms due to the ability to penetrate the biofilm matrix and the cell membrane. It is noted to the reader that sanitation in this context refers to the method of bringing a surface or object to safe levels of cleanliness for food or medical preparation and storage. Furthermore, mass spectrometry readings indicate that no contamination from heavy metals, or other toxins are present in PLA+, and PETG before and after printing. Lastly, filaments made from a pull-trusion method from recycled soda or water bottles has been tested as well. When using 3D-printed items for liquids, it is highly recommended to coat the 3D-printed parts in resin. This is a simple, fast, safe, and very effective way to smooth parts to ensure easy cleaning.
- Where to Recycle Filament?
I have a huge bag of filament waste. Where should I send this? I know it is only commercially recyclable in like very specific cases so stuff like PLA will almost never be recycled. However, I do hear of companies accepting filament and they sell back the rolls and stuff. I'm not looking to make a profit or anything, just gotta get this off of me and I want the most sustainable way to do so.
- Retraction Test
I read through the Orca Slicer manual on github, but I don't understand how the retraction test works. I have no idea how I'm suppose to distinguish the results. Would anyone like to explain in layman's terms what it is I'm looking for?
- [Work In Progress] Parametric OpenSCAD calendar
So, I'm making a fully customizable calendar in OpenSCAD with the following features:
- correct columns for every date - uses an algorithm to calculate the correct day of the week for any date, you just change the year and the calendar is correct
- fully translatable
- supports custom holidays
- supports both MMU/AMS and single extruder (with the help of M600 or similar)
Planned features:
- configurable holes for magnets or holes for hanging the calendar
- configurable first day of the week
I can share the SCAD file, though beware it's a work in progress and I haven't test printed it yet.
Some screenshots:
Click here to view the screenshots
UK calendar with holidays 2024:
UK calendar with holidays 2025:
Czech calendar with holidays 2024:
---
What do you think?
- I design and 3D Printed the smallest friction hing, I think is possible at 10mm
So I wanted a small, and thin friction hing for another project, and I couldn't find the metal ones that they use for the iPad's Magic Keyboard case. So I design my own the parts I had on my desk.
The smallest nut that I had was 4mm wide which really limited how thick the design can be. The result is this
It folds flat at measure at a maximum thickness of about 10mm
It works a lot better than I thought it would, especially since this is my first prototype print. Need to figure out some things, like to stiffen the arms and to prevent/reduce twisting.
But as a basis to start from this works nicely. I think if I add a TPU washer on the back end, I might be able to get it stiffer and more consistent feeling. But I'll do that at another time.
- Is the Sovol SV08 worth it as a Voron 2.4 alternative?www.sovol3d.com Sovol SV08 350*350*345mm Core-XY 3D Printer With Camera
Shop best budget 3d printer with advanced features on Sovol official Store, founded in 2018. Ship in 24 hours, 2-4 days for delivery, 1 year warranty. 24/7 customer support
The SV08 is marketed as a mass-produced Voron 2.4, with a much lower price and a very quick setup. They even say they donate a small amount to the Voron project for each sale.
Has anyone here bought/tested it? What are your thoughts about it?
Are there some limitations/downsides compared to a Voron?
Is it possible to upgrade it Voron-style (Stealthburner, enclosure etc)?
- OrcaSlicer V2.1.0 Official Releasegithub.com Release OrcaSlicer V2.1.0 Official Release · SoftFever/OrcaSlicer
This is the official release of OrcaSlicer V2.1.0 This update includes minor fixes and new translations. For a detailed list of all the new features, please refer to the release notes for v2.1.0 Be...
- Let's talk about Prusa Printables contests. It might need some fixing.
Currently, Prusa is doing a terrible job with the Printables competition, to the point where they could be in legal trouble if someone were to push for it.
A few examples to prove this statement (5th is in my opinion the worst):
-
insect hotel -> canceled due to security concerns. Great work, but why not look into it before you start and provide a design guideline? https://www.printables.com/contest/436-insect-hotels
-
Bathtub toys -> Mentioned explicitly: "Safety is our top priority, so make sure your creations are child-friendly, [...]". As these are bath toys, one might assume that they mean safety standards for young children. https://www.printables.com/contest/428-bathtub-toys
Great. Safety is a top priority. So let's see how they moderate it. They haven't... If you scroll through the valid submissions, there are dozens that aren't safe for children. Prusa is EU, so I would expect them to be familiar with the basic EU regulations for children's toys when they say we want safety first. There are very strict test requirements that a toy has to meet. The simplest one is a bin/cylinder that a part cannot fit into (choking hazard). Does every design meet this very basic design rule? No. Next comes impact resistance and the like. Does the design meet these requirements? no.
You could say that it's just not feasible to review every submission, so let's take a look at the winning entries that they definitely looked at: Rubber Band Submarine. I'm not a toy designer, but I'm pretty sure that an exposed rubber band is not safe for small children, who are the target audience for bath toys.
-
fish tank tweaks: Recommending PLA for prints that are permanently submerged ("It is usually recommended to use ABS or specific food-safe PLA..."). Seriously???? These days they are PLA under these conditions is rubbish within a year. Discoloration and expansion destroy some PLA blends/filaments.
-
soldering aid: Seeing this design as a winning soldering aid raises serious questions as to whether the person involved has any practical experience in assembling electronics. Placing a PCB 2cm in the air with sharp objects around the mounting holes is the opposite of ergonomic and comfortable SMD soldering: https://www.printables.com/model/740818-parametric-stackable-pcb-standoffs-m2-m14-holes
****5. This contest had questionable practices and here's where things get wild. Now we're not just talking about knowledge gaps, we're talking about breaking your own rules, which could be a legal problem. One of the contest rules states: "A valid entry may change its slope, altitude or distance." Simple. Right? Not for Prusa: https://www.printables.com/model/837104-the-rig-r11-diy-helper-stand-for-testing-electroni
This is a winning entry that can't do any of those things, and would probably qualify as a generic holder (also not a valid entry).
Another winning entry that wouldn't be a valid entry if Prusa followed the contest rules: "Skip the organisers: We love a tidy workplace, but today we're focusing on ergonomic improvements": https://www.printables.com/model/808502-heat-insert-press
Want a third from the same competition? Here it is: https://www.printables.com/model/808502-heat-insert-press "Specific adaptability: Designs must provide flexibility in the user's interaction with the tool or aid (height, tilt, distance or orientation adjustments). Simply accommodating different sizes of objects doesn't quite fit the bill".
To recapitulate, Prusa broke the rules not once, not twice, but three times within this competition (which, being EU, has some legal requirements on how you can and can't run competitions) by awarding prizes with monetary value and talking them away from other competitions that followed the rules.
There is more wrong with how this was organized/done, but I think this is damning enough. Never assume evil, so I would kindly call it Prusa being utterly incompetent.****
- The current XPR challenge. Design a part for a robotics kit. Sounds exciting. First bummer, it's $115 + tax, but that wouldn't be noteworthy enough to write this:
6.1 To design for it a.) either buy it (providing a $35 discount if you do so) or b.) try to work with whatever this is: https://www.printables.com/model/576581-xrp-robot-part-of-the-experiential-consortia/files the picture shows a complete model with PCB and sensors (some connectors and wiring are missing) but would be workable. What do they actually deliver? The frame with no electronics or components. Good luck working with that.
6.2 While this may or may not go in the direction of predatory, there is more: "Photo quality - Well lit, in focus and clear photos will help showcase your work and help us choose the best designs." Quick questions: How do I take good and compelling photos without the $115 robot kit? | Prusa: "This also means that you don't need to own a 3D printer to enter". Question: "How do you make photos without a 3D print to show of? the wording is very clear that they mean photos and not computer 3d-Render. Just by looking at these two aspects, this thing has a $115 + tax ticket to improve the "chance" of winning.
6.3 Moral issues: This work is unpaid to begin with. Does Prusa really expect people to spend tens of manhours working on a good design, printing it, taking pictures, writing instructions and text, when they have absolutely no use for it themselves, since this kit has probably only been sold a handful of times to end users. There is only a small chance of wining something (remember exhibit 5 where they didn't even follow their own rules)?
Last but not least: "Popularity – Share your model to increase its popularity, and prove that users appreciate such a model." This is fairly common for some events and I always dislike it as this asking for free advertisement. Prusa at least limits it to the model itself while others use a broader approach where it is for the entire project/organization. Regardless such terms always have a negative impact. Just remember all the MakerWorld spam everywhere after they launched with high rewards.
-
- Dry your filament!
I love in Colorado, which is a pretty dry state, so while I had heard of "wet filament", I never considered it to be a problem that I would have to worry about. I had seen people creating dry storage bins for their filament, but figured that must just be for people in humid climates.
When I first bought my 3D printer a few years ago, I did what most people probably do - I bought a 10 pack of different filament colors. Everything printed great for a while, but eventually, my prints just started to kind of suck. I made a few upgrades to my printer, but still couldn't pinpoint what was going on. What was frustrating, is that some times my prints would be great - but other times I couldn't even print the most simple prints without problems.
I eventually noticed that my great prints were from newer filament that I had recently purchased, but my bad prints were coming from spools I've had sitting out for a while. So I purchased a $40 filament dryer on Amazon and it instantly fixed all the problems I'd been having.
I feel dumb, because I had gone through three different extruders, new hot ends, new nozzles, tubing, and spent tons of time cleaning and tightening stuff on my printer. I had left my printer untouched for months because it was just so frustrating. Something as simple as old filament left out never occurred to me until much later.
TLDR; If your prints have started to suck after a while, you might want to try drying your filament.
- A nice little mushroom shelf for my ZimaBlade NAS
It’s just this design, lightly sanded and painted.
- [Troubleshooting] Random EOF shutdowns from Klipper.
Hi everyone, a week ago my printer (heavily modified Neptune 3) started randomly shutting down in the middle of prints. I come back to a print with the "Klipper reports: SHUTDOWN / Lost communication with MCU 'mcu'" error message.
The printer has been "under construction" for the last couple of weeks, but it has been in varying states of "working" for most of the time - working well enough for me to print the parts I needed to get it back to "fully operational". During this time, the printer never shut down like it is now.
Only once I started making little cosmetic changes did the problem present itself. I was running a known-good print, and I got the above error twice (first time after ~2 hours, second time after ~1 hour) before I got a successful print off of it. This was last week.
After this successful print, I continued other prints with no issues. After a day or two with no problems, an hour long print threw the error at me four consecutive times between 10-45 minutes into the print. This is when I started looking into my klippy log and found some relevant articles citing things like EMF interference, bad power supplies, faulty cables etc. I realized that one of the changes I had made rerouted the printer USB cable right around the Z-stepper, so I rerouted it to how it was originally and immediately managed a successful print. This was 5 days ago.
After moving that cable I had no issues with printing several-hour long prints... until last night. I had been printing all day, then the problem came back. After one print finished, I queued up another print with a plate full of parts, it failed after 1.5 hours. Tried the same print again, failed in 30 minutes. I re-sliced to only a handful of parts to see if I could get those to print before the error occurs, and it's failing 15 minutes into the print.
The printer power supply is the unit that came with the Neptune, and it isn't powering anything besides stock hardware (exception being the SKR mini board), so I don't think it's that. The pi is on a quality unit. The USB cable has been working for a long time so I also don't suspect that, but I'm probably going to buy a new one today just to be sure. I adjusted my enclosure setup so that the Pi and SKR are able to get cool air (at one point had a personal fan pointing at the open electronics box, still failed).
Here is a link to my most recent klippy log (abridged to the start of the last failed print). I'm not very familiar with reading through this and finding oddities, but I do think it's strange that it seemed to load my preheat script in the middle of printing right before the EOF error. (It should be noted that this preheat script was made 1 or 2 failed prints before this most recent one, so it isn't the source of the error as prints were failing before the script was made). If there's anything I'm missing or something else I can try, please let me know!
Edit: While typing this post, I was running the same failed print without filament and both heaters turned off. It ran for about 45 minutes (most recent failure occurred at 12 minutes) so I cancelled the print and started it again with heaters turned on, still without filament. It again ran for about 45 minutes, so I again cancelled it and started the print again, this time with filament loaded. It failed in 5 minutes.
Edit 2: A test print with heaters on and no filament failed after 1h8m. So it isn't an issue with extruding filament.
Edit 3: New cable with the 5v leads taped off per @SzethFriendOfNimi@lemmy.world's advice. Ran the print without filament until completion. Reloaded the same file with filament, print ran without issue until the 1h14m mark, at which point I tapped my Klipperscreen device to wake up the screen, and as soon as it displayed the status, the printer errored out. This can't be a coincidence, can it? Whenever the print goes unmonitored for a long time, it fails as soon as I do something (load mainsail, turn on the klipperscreen) to check the status of it.
- Newbie printer suggestions.
Would be so kind as to suggest a printer for me? I have no experience at all with 3D printers or 3D modeling. But I am super interested and have electronics and coding knowledge. I would like to print things like brackets, enclosures for custom circuit boards, organizers, keyboard plates, etc. Ideally I would like to spend around $300USD, but I am open to going as high as $500USD if it would save me headaches and make the experience more enjoyable and streamlined.
Please suggest something for me and let me know if I didn’t provide enough information. One final note, I live in range of a microcenter if that is a factor.
- [Purchased Bambu A1 mini] Low End FDM for Miniatures, Hobby Parts, and Messing Around?
Edit 2: I purchased the Bambu A1 mini. If I regret it, there will be more chances in later years. Haha. Maybe by then I can work with resin and make the really fun minis. Thank everyone who responded for your advice and help.
Edit: I am leaning against resin printing due to the lack of sufficient ventilation in my current work space and the potential for injuring my cats. I also do not plan to do exclusively miniatures; they were just the thing I was most excited for when making this post.
I looked around for a pinned thread or purchase wiki type thing, but didn't see one. I apologize if this is the wrong place.
After visiting a family member, I have decided that 3D printing has finally gotten affordable enough for me to maybe add to my list of hobbies. My primary use cases would be making miniatures (no particular scale necessary, as I just like to paint them at the moment), making parts for other hobbies (including cross stitch), and just generally making gifts and fun knick nacks. My budget is no more than $250 for the machine itself. I have not-insignificant computer experience, and some training in CAD programs.
Several seem to be on sale in the US for Father's Day (today), and I was wondering if anybody had some advice or suggestions on some specific ones.
- Creality Ender-3 V2 is what my family member has had for a while now and enjoyed, and less than $200 is very nice. It does seem to be dated at this point, and Creality support seems to be lacking.
- There's also the Neo of the above for the same price, but I am honestly having a hard time pinpointing the difference.
- Sovol SV06 seems to be a common recommendation for the price range, but I've heard similarly negative things about their support, especially on Amazon (although I no longer trust Amazon reviews very much).
- Flashforge Adventurer 5M appears to be on a significant sale on their official eBay (240 USD), but I have only really seen it recommended in almost spammy manners, which seems like either excitement for the sale or an ad campaign.
Any help you can give is greatly appreciated, even if it's just not getting into the hobby at this price point.
- [Solved] Help wanted
Update: TL;DR: I cleaned the z-axis, replaced the nofep, installed the latest Chitubox (2.1) and cleaned up my profile to get it working
Hello, I hope someone will see this and be able to at least point me in the tight direction. As at this point I’m becoming desperate.
My Epax E10 4k is acting up, and I do not know why.
Part of the print is fine (see images) and then other parts are just stopped at a certain layer, with the rest stuck to the noFep.
I tried different prints, to make sure it wasn’t a layering problem, but alas… each single print suffered from the issue. The larger prints would ‘hang’ over non-printed layers…
I recalibrated my printer, changed the fep…
The one difference from before is the resin. I used to buy epax hard and tough, but my regular resin dealer doesn’t sell them anymore, heck it seems it is no longer available in europe. So I switched to the next best thing on the Epax compatibility list: eSun hard and tough.
Anybody have any clever idea?
- What speeds do you use on Ender 3 V3 SE
I upgraded to this guy from the neo v2, and he is a beast in comparison. There isn't a premade profile on prusa for it though, so I made one using the neo as a base. Currently have the speed set to 150 mm/s and 1800 mm/s accel but was wondering what kind of speeds y'all are getting while still having consistent quality
- Just switched from a K1M to a P1S and it's night and day
I mostly loved my K1 Max but could not get the x-axis dialed in properly, so any time I tried to print anything with a circle it would come out a bit lumpy. I'd sold my CR-10 and upgraded because I was tired of the constant tinkering and just wanted a tool that, while it will need maintenance and the like, would mostly just do what I wanted. Also my BIL got a P1S and I was hugely envious of the AMS system haha.
Luckily a buddy was looking to upgrade as well and is buying my K1M off me so I ordered a P1S and just got it set up today and.....it's just working and I'm so happy. Benchys between the two look about the same, although the textured build plate gives a nice bottom layer, but I printed a couple trinkets my wife likes to hand out at Disneyland and it's just night and day better quality.
I'm sure I got a bit unlucky with the K1M and lucky with the P1S but it was amazing just printing stuff and it came out fine the first time.
- [OpenSCAD] Configurable household task plannermakerworld.com Configurable Household Task Planner by Rikudou
V3 updateAdded support for choosing a different font due to the inability to use Korean. For Korean I recommend downloading the font Noto Sans KR and then setting the font in the customizer to Noto Sans KR:style=Regular. You can also use the Makerworld customizer which has the font installed.V2 upda...
I made a configurable Task planner that you can easily edit using OpenSCAD customizer (or various compatible customizers like the one on Makerworld).
I've posted this here once already some time ago, so here's what's changed:
- tasks can now be provided as a comma-separated items
- font can be changed in customizer (added due to a request for Korean language support)
- how to make inlays for nail polish for labeling prints
YouTube Video
Click to view this content.
This seemed neat!
- Recommendations for STL sculpting tools or guides (FLOSS preferred)
Quick question to the community, does anyone have some good tools to sculpt stls or step files?
Context, I'm working on some decorative keychains and have a vector image and text I want to add to the base object. I've used aolidworks for both in the past with alright results but I've switched over to freecad this year, haven't had a lot of luck adding in there, vector image is a tracing of a dog that I was provided, it's simplified but still has a lot of components.
I did look into blender but be honest I'm totally lost using it and have no clue what I'm doing coming from parametric modeling, I'm not an artist at all, my comfort zone is functional parts usually, but was approached by a friend. I did do some mockups in prusa/superslicer where I've added my image and text as negative volumes and merged into a single part. It works but it feels like a really hacky workaround (relevant XKCD) and would prefer to do it right. Any suggestions or resources would be appreciated!
If interested, here's the mockup that I've done a few test prints on, found I needed to change the line width of my vector a few times and made some features exaggerated so they'd come out more. I've (poorly) covered some identifying text on the back, left the rest as to get a feel for what I'm trying to do, did do some rough sanding on the below pictures. There's a pocket on the top edge that accepts a keyring, it's kinda chunky, about the size of a pog slammer or a thicker poker chip.
!Rough Sanded Front of keychain with image of a Bernese Mountain Dog!Back of keychain with some details obscured
- Misschanger - Design Freeze
YouTube Video
Click to view this content.
My MissChanger project is a Stealth Burner tool-changer system for Voron 2.4 and Trident.
And it is going along great 😚
- Alternative Printer Uses
"You need to buy this special heater pad to break the screen adhesive!"
No, I think you will find that in fact I don't.
- I made a thing! (Bluetooth speaker modeled from scratch)
No banana for scale, but let's say that it's not too big and not too small. The dimensions are 295mm tall, 270mm wide, and 240mm deep. If I had to do it again, I would be tempted to go a bit wider and touch less deep. It's probably better to be large in one of these dimensions as opposed to both of them.
Here's the top. It has a jack for charging, a connector to program the DSP, a switch to turn it on and off, and a battery gauge.
The speaker also has a built in handle that's way chunkier than it appears, but is still particle.
The big BOM pieces are a Dayton Audio LBB-5Sv2 for the BMS (battery management system), a Dayton Audio KABD-250 2 x 50W for DPS, amplification, and Bluetooth, a Peerless by Tymphany BC25SC08 tweeter, and an Italian-but-made-in-India woofer (a Coral PRF 165).
The print itself is three pieces: the bottom bit (black), the middle bit (white, blue, and white again thanks to not having enough white left to do it all in white), and the black top. Here's a CAD view that more clearly shows the three pieces:
the three pieces are held together with heat-sets and m3 bolts. There's also a tong and groove like joint to help the enclosure leak less air. I haven't noticed any evidence of air leaks while listening.
The amplifier and battery board mount to the bottom like so:
The middle was printed with some supports for the driver overhangs, but the ports and everything else were designed to print in place without supports.
This is certainly not meant to be audiophile build, but it's surprisingly decent. This isn't my first blue-tooth speaker, or even my first printed loudspeaker enclosure, but it is the first that was somewhat intentionally designed to have OK bass response while also being reasonably compact.
It measures fairly well. Frequency response, along with harmonic distortion, is pretty good. There's zero windowing or smoothing on this plot. I suspect the distortion spikes at 1 kHz, 2 kHz, etc are induced by the Bluetooth stack the board is running since they've shown up in multiple different enclosures and with multiple different drivers.
There's no nasty ringing, caused by either the drivers or the enclosure, so life is pretty good:
- Got a Bambu P1S but the build are low quality
Hey guys I got the bambu P1S a couple months ago because it was recommended. I'm super new to 3d printing. This is my first one. I'm not new to electronics or computers. I ran a few of the built in prints, a dinosaur puzzle and this scraping tool but both came out fuzzy and in poor build shape. What can cause this? Shaky table? Cold temps (the printer is in my insulated garage getting around 65 degrees at the moment inside)? Is the stock bed bad? The filament it came with bad?
- Any thoughts on a fully printed voron?
Hi guys, been thinking about this for a couple weeks now but can't seem to find anything online about anyone who has tried it.
I'm considering converting my printer into a voron. However, since I currently have a fully functioning printer, I wondered why I can't print the extrusions rather than purchasing them? Of course they are larger than my printer's volume, but there was this video posted here a while back about a great way to create strong permanent joints for parts just like this:
https://youtu.be/zI8OgRRF5d8
The way I would do this would be to model the extrusions as a solid piece and make cutouts in the areas that bolts are meant to be ran through.
Is this even within the realm of possibility, or is there a specific barrier that has prevented others from trying this? The obvious concern is stability/ rigidity, but if everything is printed at voron part standards or thicker with an infill pattern like gyroid, would the decrease in rigidity be too much for input shaping to compensate for?
Thanks for any ideas or input! If there aren't any major road blocks or examples of this failing I think I'll try it out once I've got the space for it.
- Seeking advice choosing a multi-color printer
Hello,
I am trying to figure out which printer with multi-color capabilities to buy, and I'd like to hear some other people's opinions.
Note: I can't buy Bambu Labs products, so please do not recommend one.
Current options:
- Prusa Mk4 and MMU3.
- Voron 2.4-style (either Formbot kit or Sovol SV08) and ERCF, and eventually DAKSH toolchanger.
- Ratrig V4 and the upgrades when they come out.
- Creality K2 Plus (when it comes out).
- Qidi Q1 Pro and the rumored multi-color unit.
My current thoughts:
- I am happy wait a bit if that's the best option.
- I like the fact that the MMU3 mechinism doesn't waste as much filament as some other mechanisms. It's easier for me to pay more up front for the mechanism than constantly keeping tons extra filament in stock.
- The potential for a Voron to be upgraded to a toolchanger with DAKSH is intising.
- High print quality is important to me, although I can't imagine any of these would result in bad quality.
- Prusa XL is outside my budget :(
Please let me know your opinions, and thank you to anybody who read this far.
- Turbocase Generates A PCB Shell For Youhackaday.com Turbocase Generates A PCB Shell For You
Our PCBs greatly benefit from cases – what’s with all the pins that can be accidentally shorted, connectors that stick out of the outline, and cables pulling the board into different di…
- How often do you lubricate the linear guides?
I am curious how often do you service the linear rails on the 3D-printer:
- How often do you lubricate them (MGN9 or MGN12)?
- How do you lubricate them?
- What volume of lube do you use?
Explanation of how often you should do it (HIWIN Lubricating instructions for linear guideways and ballscrews)
Most 3D-printer use MGN12. Reading the HIWIN documentation they shall be lubricated every 20-50km (depends on a lot of factors).
How much is 50km in print time? Assuming an average speed of 300mm/s that would be approx. 46 hours!
In other words, the generic MGN12H carriage needs 1-2 times per week maintenance.
How much lube is suggested (horizontal mounting)? 70µL for MGN12H. For MGN9H it is 30µL!
- Printable make posting locked behind purchase?
Don't think I've seen this before. Don't even think the author has things for sale from what I can tell. Couldn't find an obvious option on any of my models to toggle this either.
Anyone know what's going on?
- help with clogged Mk4 hotend?
Total clog with prusament pla in line. Can't feed anything through even at high heat. Cold pull not possible / filament not making it into hot end to do this.
You can see little bit of filament sticking out in photo, but with pliers this just tears.
Should I try heating up the whole hot end tube with a soldering iron to see if I can liquify the clog out? Any other ideas? I can't find many good resources about what to do in this situation online. Also, obviously needs to get cleaned up a bit, but does picture of my hot end tip look pretty ok? Do I need to bite bullet and get a new hot end? If so, are Amazon off brand replacements ok, or do I need to wait for one to get shipped from prusa?
Thank you
- [Repair] Creality K1 Max, and it being shipped with a different variant. A post in case anyone runs into this in the wild.
So I run a repair shop in Altamonte Springs, FL - Got a weird one that searching the internet only turned up 1 other instance of it happening, so I wanted to post some details on the repair in case someone else runs into it or in case Creality doesn't admit that it's a thing.
Creality K1 Max - Symptoms: Unable to finish initial calibration. X and Y Axis moving twice as far as commanded, auto leveling absolutely destroying the build plate.
Initial steps in fixing this were to replace the main board. Creality shipped some of these printers with some interference around the main board which could have screwed up the drivers. Many references to this across the internet.
After replacing the main board, it still would not get past the input shaping setup, so the next thing to replace was the toolhead board on the K1. It seems the accelerometer on this one was either A: Damaged by the customer in their attempts to fix, or B: Faulty from the get-go.
After replacing the toolhead board, the machine would get past the initial input shaping, but it would do it in the back left corner of the machine (from experience, this should be done in the center of the plate). So upon homing, I also noticed that it wouldn't regularly go all the way to the front right of the machine. When commanded to go X negative, 10mm, it would go like 24mm instead.
In the end, I needed to: Replace mainboard, Replace toolhead board, let the machine crash into it self for 20+ minutes while going through Auto-leveling on the initial power on stage, connect it to your network, upgrade the firmware, DO NOT HEED the warning that you need to auto-calibrate again.
Follow this guide to root it: https://guilouz.github.io/Creality-Helper-Script-Wiki/helper-script/helper-script-installation/
THEN, after it's rooted, install Moonraker/Nginx, Moonraker or Fluidd, then connect to one of those interfaces, edit your printer.cfg and change rotation distance to 72 for this variation of machine.
If you notice that the sensorless homing is not acting perfectly due to the different step-size of this machine,
driver_SGTHRS: 55
is the configuration option you're looking for, and you need to set it on both X and Y. 55 worked for me, but the default is 75. 0 is least sensitive, 255 is most sensitive. I had to set mine to be less sensitive to finally work.Once you've made these changes, you can save/reboot and test out homing/movement once again. If everything seems okay, go ahead and run the self-test to complete the repair.
- tiny desk shelves
Tiny desk shelves for kiddo. Stl https://www.printables.com/model/713135-tabletop-shelf-rack
- Was trying out a new stitch to attach leather to my 3D Printed part. I love the results
Here is the reverse side:
For the long and short of what this is. I make 3D Printable e-reader cases that are held together by stitching cloth or leather. Up to now the cover had the magnet as a part of the design, but with no way to upgrade or change it out. This is my solution for that.
With 8 screws and a tight fit, the cover can be swapped out when you upgrade or change out your e-reader. That way you can keep the case itself and just upgrade the components you need when you need it.
Still testing it, but very happy with how it turned out.
- Is Carbon fiber PLA filament safe to handle?
I've been looking into this material due to the really nice surface finish and clean look (actually purchased some already 😅)
However I recently came across a video by CNC kitchen where he raised some potential health concerns relating to the fibers specifically inside the filament. One of the commenters mentioned they couldn't wash the fibers off their skin, and another likened it to the "3d printing equivalent of asbestos"
I don't plan to print with it just yet due to needing a hardened nozzle, and spare extruder parts. However when I do, i'm feeling a little worried about how safe it is - mainly whether the final printed part is fine for occasional skin contact, or whether this material should ideally be left to just cosmetic parts.
P.S. image not mine, taken from here
- Nesting capabilities of slicer (overview)
Short overview of how good the nesting capabilities of various 3D slicer are.
The task is simple: placing as many of these shapes on a 200x300mm printed as possible. Manual (quick and dirty for reference): 6 pcs.
Ranking:
- Ultimaker Cura: 7 pcs.
- human (me): 6 pcs.
- Orca slicer: 5 pcs.
- PrusaSlicer & BCN3D stratos: 4 pcs. By switching (for this particular part) from the worst (Prusa) to the best (Cura) slicer the nesting performance improved by a whopping 75%!
Ultimaker Cura:
Prusa:
BCN3D Stratos (forked from an old version of Cura):
OrcaSlicer:
- DIY 3dprinted buggy
cross-posted from: https://sh.itjust.works/post/19906943
> Had some left over rc junk, challenged myself to make it go without my usual over designing/thinking/planning procrastinating until I never even start. happy how it turned out! reminds me of a tyco bandit, probably shorten v2 even more and stick that bandit body on.
- Can't post an image, I get a 413 error.
As the titles says, I tried to post a 2.2mb image and get a 413 error. Any help?
- CR 6 Max extruder issue
I have a CR 6 Max and I took apart the extruder and now whenever I put it back there are always problems.
Firstly the spring is impossible to put back correctly so it never aligns perfectly.
When I managed to screw in the screws such that is was as good as I could make it, now the filament does not insert properly.
How do I proceed from here? Is there an easier way to put it back together? Is it possible to get another extruder that works differently but is compatible with the cr 6 max?
